The Luke maintains a reparatory light plot that is hung, circuited, gelled, and ready to go. Originally designed by Ted Dolas, this plot has been refined over the years to serve the various and diverse entertainments that come to The Luke. Our plot is well suited, with minimum changeover and maximum crossover, for everything from Dance to Lectures, and Drama to Chamber Music.
At a glance, our reparatory plot has 7 stage washes including 2 colors of front light, 2 colors of back light, 2 colors of side light, with 1 color of high side light. For background color, we have 5 Ovation B-2805FC focused as cyc lights on our 18’x40′ natural colored cyclorama, as well as utilizing 4 color striplights hung at midstage for apron color splash. Specials are hung throughout the plot with 9 specials hung on center and quarter lines above the stage and 4 specials front of house. Changes to our reparatory light plot may incur additional fees.
Light Plot
Instrument Schedule
Lighting Inventory
Power:
20/208V. No Company Power Available.
Dimmers:
(192) Strand™ SLD 2.4 kw dimmers
Control Board:
ETC Ion with 2×20 fader wing
House Light Control:
In the Sound Booth, Lighting Booth, and SR.
Circuits:
(192) 2.4 kw circuits
On Stage:
(12) stage Floor pocket circuits,
(3 raceways) on-stage Electrics,
(2 raceways) on-stage Border Pipes,
(4) 6-circuit Drop Boxes (SR and SL Ladders)
FOH:
(16) House Boom positions,
(4) Balcony Rail positions,
(48) Ceiling positions (Apron, 1st, and 2nd AP’s)
Instruments:
All instruments are equipped with stage pin connectors
(72) 19° Strand™ SL Series ERS, 575w
(34) 26° Strand™ SL Series ERS, 575w
(35) 36° Strand™ SL Series ERS, 575w
(12) 50° Strand™ SL Series ERS, 575w
(12) 26°-50° Zoom Strand™ SL Series ERS, 575w
(60) Strand™ 6” Fresnelites (Theatre), 1kw
(30) Source-Four™ Par Lights w/ lens kits, 575w
(12) 12-cell, L&E™ BR40/PAR 38 4-circuit border lights, 250w/cell
( 6 ) 2-cell Sky-Cyc™ lights, 1kw/cell, stage pin
Follow Spots
( 2 ) Mighty Arc II™ Follow Spots,
Hardware
(16) 24” double-tee side-arms
(35) 6” barn-doors
(24) pattern holders
Cable
all cable is stage pin
(24) 5’ extensions
(18) 10” extensions
( 6 ) 25” extensions
(16) two-fers
